ASM78P 605-625 Series N-type Solar Panel
Product Description

605-625W                             22.36%                         0.55%




POWER RANGE      MAXIMUM EFFICIENCY        YEARLY DEGRADATION


12 YEARS PRODUCT WARRANTY        30 YEARS OUTPUT GUARANTEE


IEC 61215/IEC 61730/IEC 61701/IEC 62716/UL6 1730

ISO 14001: Environmental Management System

ISO 9001: Quality Management System

ISO45001: Occupational Health and Safety Management System

*As there are different certification requirements in different markets.please contact your local znshine sales representative for the specific certificates applicable to the products in the region in which the products are to be used.

*Please check the valid version of Limited Product Warranty which is Officially released by Anhui Shangxia Solar Energy Co., Ltd.


Excellent Cells Efficiency

MBB technology reduce the distance between busbars and finger grid line which is benefit to power increase.



Anti PID

Ensured PID resistance through the quality control of cell manufacturing process and raw materials.



TIER 1

Global,Tier 1 bankable brand,with independently certified advanced  automated manufacturing.


Bifacial Technology

Up to 25% additional power gain from back side depending on albedo.




Better Weak Illumination Response

More power output in weak light condition, such as haze, cloudy, and early morning.



Adapt To Harsh Outdoor Environment

Resistant to harsh environments such as salt, ammoniasand, high temperature and high humidity environment.



Excellent Quality Managerment System

Warranted reliability and stringent quality assurances well beyond certified requirements.


ELECTRICAL CHARACTERISTICS  丨 STC*


Nominal Power Watt Pmax(W)*

605

610

615

620

625

Power Output Tolerance Pmax(%)

0~+3

0~+3

0~+3

0~+3

0~+3

Maximum Power Voltage Vmp(V)

45.42

45.60

45.77

45.93

46.10

Maximum Power Current Imp(A)

13.32

13.38

13.44

13.50

13.56

Open Circuit Voltage Voc(V)

55.17

55.37

55.44

55.58

55.72

Short Circuit Current Isc(A)

13.95

14.03

14.11

14.19

14.27

Module  Efficiency (%)

21.64

21.82

22.00

22.18

22.36



















MECHANICAL DATA



Solar cells

Double  glass

Cells orientation

1446×24

Module dimension

2465×1134×30mm  (With Frame)

Weight

34.6 kg

Glass

3.2mm, High Transmission, AR Coated Tempered Glass

Junction box

IP 683 diodes

Cables

4 mm² ,350 mm (With  Connectors)

Connectors*

MC4-compatible

















ELECTRICAL CHARACTERISTICS 丨 NMOT



Maximum  Power Pmax(Wp)

455

459

462

466

470

Maximum Power Voltage Vmpp(V)

42.23

42.35

42.46

42.57

42.68

Maximum Power Current Impp(A)

10.77

10.83

10.89

10.95

11.00

Open Circuit Voltage Voc(V)

52.41

52.54

52.66

52.79

52.93

Short Circuit Current Isc(A)

11.26

11.33

11.39

11.46

11.52













TEMPERATURE RATINGS*                                                   WORKING CONDITIONS


NMOT

45℃ ±2℃

Maximum  system voltage

1500 V DC

Temperature coefficient of Pmax

-0.25%/℃

Operating temperature

-40℃~+85℃

Temperature coefficient of Voc

-0.25%/℃

Maximum  series fuse

30 A

Temperature coefficient of Isc

+0.045%/

Front Side Maximum Static  Loading Up to 5400 Pa

Refer.Bifacial Factor

         80±5%

Rear Side Maximum Static  Loading Up to 2400 Pa

















Double-sided generation parameters (back gain)



5%

Maximum Power (PMAX)

635

641

646

651

656

Component efficiency (%)

22.73

22.91

23.10

23.29

23.48

15%

Maximum Power (PMAX)

696

702

707

713

719

Component efficiency (%)

24.89

25.10

25.30

25.51

25.71

25%

Maximum Power (PMAX)

756

763

769

775

781

Component efficiency (%)

27.05

27.28

27.50

27.73

27.95
